0.6 First Day Assignment

1. Back Up and Open Your Existing First Day Solution

Your First Day solution was renamed to your last name in 0.2. Keep that working name for the rest of the sequence. At the beginning of each module, make a backup of the completed previous checkpoint, then continue working in the original student-named solution.

Step 1 — Make a checkpoint backup

1. Close Visual Studio if the solution is open.
2. Locate the working parent folder named with your last name.
3. Make a backup copy and label it First Day 0.5 Backup LastName.
4. Leave the working folder name and LastName.sln unchanged.
5. Open LastName.sln from the working folder.

Step 2 — Verify the previous checkpoint

1. Build or run the solution before making the new 0.6 changes
2. Verify the major behavior you completed in 0.5 is still present
3. If the previous checkpoint is not working, correct that starting state before adding the new module work

2. Inspect the Supplied CSV

A CSV file stores structured information as text. Each line follows a predictable pattern, which lets software recognize fields and records rather than treating the entire file as one undifferentiated block of text.

Step 1 — Open Courses.csv before running any code

Open the supplied Courses.csv file in a plain text editor.

CourseCode,CourseTitle,Credits
EX101,Digital Systems Basics,3
EX205,Web Foundations,2
EX310,Working with Data,3
EX415,Technology and Society,1

Step 2 — Identify the structure

1. Identify the header row
2. Identify the three field names
3. Identify the first complete record
4. Identify the value stored in the first record's CourseTitle field
5. Identify how many records appear after the header

Step 3 — Compare with the 0.4 text file

The 0.4 shopping-list file preserved text, but it did not establish a fixed set of named fields for every line. The 0.6 CSV uses the same fields for every record.

3. Connect the CSV to Class and Object Diagrams

You have already used UML class diagrams to describe reusable structure and object diagrams to describe one particular instance. A structured CSV provides a useful way to revisit that distinction.

Step 1 — Read the class diagram

The conceptual CourseRecord class describes the fields one course record can contain.

Compare the class attributes with the CSV header:

CourseCode,CourseTitle,Credits

Step 2 — Read one record as an object

The first CSV record contains actual values. An object diagram can represent those same values as one particular instance.

Step 3 — Connect all three representations

• CSV header field → class attribute
• CSV row → one record/object
• CSV cell value → one value in that record/object

4. Add the Structured-Data Files and DataGrid

The parser is supplied because CSV parsing is not the focus of this course. You will add the supplied files, then add a DataGrid so the loaded records have a visible row-and-column representation.

Step 1 — Add the supplied files

1. Download Courses.csv
2. Download CsvData.cs
3. Add both files to the FirstDayScenario project
4. Keep the filenames exactly as supplied

Step 2 — Add System.Data

Open MainWindow.xaml.cs and add the following line with the other using statements.

using System.Data;

Step 3 — Make the growing application scrollable

The First Day application now contains several module demonstrations. Use the supplied outer structure so the window can scroll rather than becoming taller than the screen.

<Window x:Class="FirstDayScenario.MainWindow"
        ...
        Title="MainWindow" Height="900" Width="650">
    <ScrollViewer VerticalScrollBarVisibility="Auto">
        <Grid Height="1260">
            <!-- Keep the existing First Day controls inside this Grid -->
        </Grid>
    </ScrollViewer>
</Window>

Keep all existing controls inside the inner Grid.

Step 4 — Add the structured-data controls

Place the following StackPanel below the existing weather section.

<StackPanel HorizontalAlignment="Center" Height="330" Margin="0,795,0,0" VerticalAlignment="Top" Width="560">
    <TextBlock Text="Sample Course Data" FontWeight="Bold" Margin="5" />
    <Button x:Name="loadCourseDataButton" Content="Load Course Data" Width="360" Margin="5" Click="LoadCourseDataButton_Click" />
    <DataGrid x:Name="courseDataGrid" Height="270" Margin="5" AutoGenerateColumns="True" IsReadOnly="True" />
</StackPanel>

Move the output area below the new DataGrid.

<TextBox x:Name="textOutput" HorizontalAlignment="Center" Height="90" Margin="0,1140,0,0" TextWrapping="Wrap" VerticalAlignment="Top" Width="560" BorderThickness="3" BorderBrush="#FFB3B3B4" VerticalScrollBarVisibility="Auto" />

Step 5 — Add the supplied button event handler

Add this event handler inside the MainWindow class with the other button handlers.

/// <summary>
/// Loads the supplied sample CSV file and displays its structured records.
/// </summary>
/// <param name="sender">The object that initiated the event.</param>
/// <param name="e">The event arguments for the event.</param>
private void LoadCourseDataButton_Click(object sender, RoutedEventArgs e)
{
    DataTable courseData = CsvData.Load("Courses.csv");
    string firstCourseTitle = courseData.Rows[0]["CourseTitle"].ToString();

    this.courseDataGrid.ItemsSource = courseData.DefaultView;
    this.textOutput.Text = "First record title: " + firstCourseTitle;
}

Check Your Work

1. Build the solution
2. Run the application
3. Scroll to the new Sample Course Data section
4. Verify Load Course Data and an empty DataGrid are visible

5. Load the Data and Trace One Value

The supplied loader reads the CSV and produces structured records for the application. You will pause after that work is complete and follow one easy-to-recognize value.

Step 1 — Set a breakpoint after the load

Set a breakpoint on this line:

string firstCourseTitle = courseData.Rows[0]["CourseTitle"].ToString();

That line deliberately pulls one field from the first loaded record into a simple string so you can inspect it without learning the CSV parser.

Step 2 — Load the CSV

1. Run the application
2. Scroll to Sample Course Data
3. Click Load Course Data
4. When Visual Studio pauses, inspect courseData
5. Press F10 once so firstCourseTitle receives its value
6. Inspect firstCourseTitle

Step 3 — Predict the DataGrid

1. How many columns should appear?
2. What should the column names be?
3. How many data rows should appear?
4. What title should appear in the first row?

Step 4 — Continue and compare

this.courseDataGrid.ItemsSource = courseData.DefaultView;

6. Change One CSV Value and Follow It

The structure will remain exactly the same. Change only one field value and predict where that changed value should appear.

Step 1 — Change the first course title

Change:

EX101,Digital Systems Basics,3

to:

EX101,Digital Systems Fundamentals,3

The complete file should now be:

CourseCode,CourseTitle,Credits
EX101,Digital Systems Fundamentals,3
EX205,Web Foundations,2
EX310,Working with Data,3
EX415,Technology and Society,1

Step 2 — Predict before running

1. Predict the new value of firstCourseTitle
2. Predict which DataGrid cell should change
3. Confirm that the field names and number of records did not change

Step 3 — Run the same application again

1. Run the application
2. Click Load Course Data
3. Use the same breakpoint if you want to observe firstCourseTitle again
4. Continue to the DataGrid
5. Verify the changed title appears in the first record

7. Final Check and Submit

Verify the complete 0.6 checkpoint before packaging the solution.

Step 1 — Complete the final technical check

1. Build the solution and correct any in-scope build errors.
2. Verify the existing clothing, shopping-list, and weather sections remain present.
3. Verify Courses.csv and CsvData.cs are included in the project.
4. Click Load Course Data and verify the CSV fields appear as DataGrid columns and records appear as rows.
5. Verify the revised first course title appears in both the DataGrid and the First record title output.

Step 2 — Zip the solution

1. Close Visual Studio
2. Locate the LastName parent folder that contains the .sln file and project folder
3. Create a ZIP file of the entire solution folder
4. Open the ZIP and confirm the solution file, FirstDayScenario project, Courses.csv, CsvData.cs, and the inherited WeatherSupport.cs are present

Step 3 — Submit to the Feedback System

1. Open the Feedback System
2. Select the correct First Day 0.6 assignment
3. Upload the zipped Visual Studio solution
4. Review the Feedback System results and correct any in-scope issues if required
5. Resubmit a corrected ZIP when needed

Step 4 — Submit the Feedback System URL to Canvas

1. After the required Feedback System submission is ready, copy its URL
2. Open the correct 0.6 First Day Assignment in Canvas
3. Submit the Feedback System URL as your Canvas submission
